打膠機設備常見的兩個問題以及應對
自動打膠機在現代工業(yè)中起到非常重要的作用，膠水通過設備運行設定打膠出來，但是打膠機在使用的過程中會出現各種各樣的情況，
濟南雙組份打膠機小編為大家講解一下。
The automatic glue dispenser plays a very important role in modern industry. Glue is injected through the equipment operation settings. However, various situations will occur during the use of the glue dispenser. The small knitting machine of Jinan two-component glue dispenser will explain to you.
一、漏膠不均勻，出現花膠
1、 Glue leakage is uneven, and there is glue
1.黑膠、白膠壓力是否平衡：白膠膠泵壓力為0.4Mpa左右，黑膠膠泵壓力不能低于0.6Mpa；2.檢查比例泵黑白配比是否為1：10左右；
1. Whether the pressure of black glue and white glue is balanced: the pressure of white glue pump is about 0.4Mpa, and the pressure of black glue pump cannot be lower than 0.6Mpa; 2. Check whether the black and white ratio of the proportional pump is about 1:10;
3.檢查混膠器是否安裝正確與清理；
3. Check whether the rubber mixer is correctly installed and cleaned;
4.檢查黑膠智能壓力表參數是否正常；
4. Check whether the parameters of the black glue intelligent pressure gauge are normal;
5.檢查黑膠氣動開關與電磁閥動作是否正常；
5. Check whether the black glue pneumatic switch and solenoid valve operate normally;
6.檢查氣動開關固定塊是否阻塞；
6. Check whether the fixing block of the pneumatic switch is blocked;
7.檢查黑膠、白膠氣動開關是否阻塞。
7. Check whether the pneumatic switches of black glue and white glue are blocked.
二、打膠不出膠
2、 Glue cannot be released
1.檢查氣源是否在0.60.8Mpa之間；
1. Check whether the air source is between 0.6 and 0.8Mpa;
2.檢查觸摸屏中編輯功能菜單中的密封不使用是否打開；
2. Check whether the seal is opened in the edit function menu of the touch screen;
3.檢查氣動開關是否阻塞；
3. Check whether the pneumatic switch is blocked;
4.檢查黑、白膠氣動開關與電磁閥動作是否正常；
4. Check whether the black and white glue pneumatic switches and solenoid valves operate normally;
5.檢查比例泵上的智能壓力表是否報警，范圍在7-35Mpa；
5. Check whether the intelligent pressure gauge on the proportional pump alarms, and the range is 7-35Mpa;
6.檢查液壓站是否有壓力，如無壓力：1)清洗比例溢流閥2)檢查比例控制器是否通電或松動；
6. Check whether there is pressure in the hydraulic station. If there is no pressure: 1) Clean the proportional overflow valve; 2) Check whether the proportional controller is energized or loose;
7.清洗時是否能出白膠，如不出再檢查313膠管、旋轉接頭是否阻塞；
7. Check whether white glue can be released during cleaning, and if not, check whether 313 rubber tube and rotary joint are blocked;
8.檢查一組比例泵下限傳感器IB233是否有信號，檢查二組比例泵IB407是否有信號；
8. Check whether there is signal from lower limit sensor IB233 of one group of proportional pumps and whether there is signal from IB407 of two groups of proportional pumps;
9.手動檢查掃描儀數值是否有正常。
9. Manually check whether the scanner value is normal.
We have explained the two common problems of the glue dispenser and the relevant solutions. I hope we can help you. Of course, you should also maintain it during use. Pay attention to us http://www.sunflowder5188.com.cn Learn more!
